SingleDisc – perfect contour adaption due to gauge wheel
Tooless depth adjustment with precise graduated adjustment
Low disturbance due to SingleDisc opener
The SingleDisc opener has specially been designed for the Avatar line. Due to its individuality and flexibility, it can be adapted to the many different seeding conditions:
The interaction of SingleDisc opener and seed boot ensures a safe opening of the furrow. At the same time, harvest residues are removed from the furrow. The result is an optimum contact of seed and soil for quick and safe emergence.
With the rubber torsion suspension, and the weight transfer system a pressure of up to 550 lbs per opener can be applied. The downforce can be adjusted mechanically or electrically via the terminal. All pivot points and connections at the opener are maintenance-free.
The durable, maintenance-free bearings on all rotating parts guarantee a long service life and operational reliability. The seed boot is equipped with a carbide wear edge for a long service life. All openers are equipped with the HM+ version seed boot. The stable gauge wheels guarantee a precise depth control of the opener in changing or difficult soils. This is due to different, coordinated adjustments of the seed opener and optional equipment's. Due to the lateral angle of 6° and a vertical angle of 3°of the single disc opener, the seed is placed diagonally below the surface. Depending on the conditions, you can choose between a uniformer for more wet conditions, and a catching wheel for all types of conditions for seed embedment.
Perfect seed placement and wide range of applications due to the SingleDisc opener
Compact, efficient, precise
